Clark WSRX30 Electric Pallet Jack – Heavy-Duty Material Handling
Shop the Clark WSRX30 electric pallet jack for efficient, reliable, and heavy-duty material handling. Ideal for warehouses, loading docks, and factories.
CONTACT US FOR PRICE
Hydraulics
Lift cylinder has hard chrome plated rods. Pump unit including motor, solenoid, gear pump, and pressure compensated lowering valve are mounted high in the power compartment for ease of service.
Electrical Componentry
Travel speed remains constant relative to throttle position regardless of load. Separately fused power control circuits, quick disconnect EPD power cut off, and hour meter /battery discharge indicator combination gauge complete the system. Power configurations and diagnostic features are displayed with a ZAPI handheld console.
Brakes
Regenerative electromagnetic brake is mounted on the motor armature shaft multiplying the braking power through the transmission. Brake is applied when the control arm is in the vertical or horizontal handle position. Travel speed is reduced when forks are above 12” fork height.
Ergonomic Controls
Travel, lift, and lower functions are located in the ergonomic operator handle. All operator controls are accessible without having to lift the hand from the handle. Angle grips are designed to allow easy operation with either hand. Wrap around guard, reversing switch, thumb control, and horn are standard. Top mounted tiller arm offers excellent operator comfort and minimum steering effort. Gas assisted spring gently returns handle to vertical position.
Transmission
Vertically mounted drive motor is direct mounted to gear housing. State of the art optimized gear technology supplies advantages such as minimal envelope circle, zero maintenance, low noise level, high efficiency, and high performance.
Mast & Pantograph
I-beam mast with dual lifting chains. Pantograph stroke extends the fork carriage beyond the unit’s straddle legs, with integral tilt and side shift.
